Using rotated tables
Rotated tables rotate the data in the data table they are attached to such that rows become columns and columns become rows.
*To create a rotated table
1. From the Tables tab in the Object Palette, select the Rotated Table object and add it to the dashboard canvas.
2. Attach the table object's valueTable property to instance data just as you would for other kinds of tables (see, for example, Creating an instance summary table).
Example of Rotated Table dialog
Here the rotated table is attached to an instance table, and the filter is set to select only the instance where Instrument equals APMA. Without a filter, all instances appear as columns.
